This is an original Haynes Owners Workshop Manual for the Ford 1.6 litre diesel engine, specifically covering the production years 1984 to 1987. The manual features the characteristic purple and white cover design associated with Haynes publications from this era. The front cover displays a detailed technical line-drawing illustration of the 1.6L diesel engine, which includes the artist mark PJ Cox within the drawing. The upper right corner features the circular Haynes logo with a book graphic set against a vertical yellow and red stripe. A diagonal purple band in the bottom right corner bears the text Every manual based on a complete stripdown and rebuild. This publication provides technical guidance for the maintenance and repair of the 1.6L diesel unit used in Ford vehicles of the mid-1980s, such as the Escort, Fiesta, and Orion. The manual is constructed with a printed card cover and bound paper pages.
270mm x 210mm.
